Product Introduction


TEST METHODCONDITIONSUNITSYB-PEEK 450YB-PEEK GL30YB-PEEK CA30YB-PEEK FC30
Charpy Impact StrengthISO 179/1eANotchedkJ m-27875
ISO 179/IUUnnotchedkJ m-2-554535
Izod Impact StrengthISO 180/ANotchedkJ m-27.51096
ISO 180/UUnnotched,kJ m-2-604535
Mold ShrinkageISO 294-4Parallel to the flow direction%10.30.10.3
ISO 294-4Perpendicular to the flow direction%1.30.80.50.7
Thermal Data
Melting PointISO 11357-343343343343
Glass Transition (Tg)ISO 11357Onset143143143143
Specific Heat CapacityDSC23℃kJ kg-1-12.21.71.81.8
Coefficient of Thermal ExpansionISO 11359Along flow below Tgppm K-14518515
ISO 11359Average below Tgppm K-112018620
Heat Deflection TemperatureISO 75-f1.8 MPa152328336315
Thermal ConductivityISO 22007-423℃W m-1 K-10.290.30.950.87
Flow
Melt ViscosityISO 1133380℃,5kgg 10min-1104.52.32.5
Other
DensityISO 1183Crystallineg cm³1.31.511.41.45
ISO 1183Amorphousg cm³1.26---
Shore D hardnessISO 86823℃
85888883
Water Absorption (3.2mm thick Tensile bar) (by immersion)ISO 62-124h,23℃%0.070.040.040.04
ISO 62-1Equilibrium,23℃%0.40.30.30.3
Electrical Properties
Dielectric strengthIEC 60243-12mmkV/mm-12325--
Comparative Tracking IndexIEC 60112-V150150--
Dielectric constantIEC 6025023℃,1kHz-3.13.2--
IEC 6025023℃,50Hz-0.004---
Loss tangentIEC 6025023℃,1MHz-0.0040.005--
Volume ResistivityIEC 6025023℃,1VΩ·cm101610161051010
IEC 60093275℃Ω·cm109---

PROCESSING EXPERIENCE TECHNICAL ADVANTAGES

Experience Advantage

01

Experience Advantage

From 2007 to 2025, we have 18 years of experience in production and support, with over 600 sets of injection molds. We have accumulated valuable experience in supporting production for numerous companies. We have been focusing on the research and development and production of special engineering plastics, composite modified materials, and new materials.

Equipment Advantages

02

Equipment Advantages

Years of production support have enabled the company to possess a wide range of production and processing equipment, including numerous large-scale injection molding machines, molding machines, high-precision CNC lathes, CNC machining centers, precision engraving machines, drilling, milling and grinding machines. The company also has a comprehensive material testing center equipped with friction and wear testing machines, insulation resistance testers, electronic universal mechanical testing machines, ultrasonic flaw detectors, two-dimensional image measuring instruments, CMMs, density meters, hardness testers, and high-temperature and high-pressure sealing testing equipment.

Technical Advantages

03

Technical Advantages

We have an experienced technical team that can design and manufacture molds of various specifications that meet customer needs in a short period of time. With a comprehensive production system, we provide one-stop services from drawing to mold manufacturing to injection molding, which can maximize the satisfaction of customers' diverse product needs and product design technical requirements.

Cooperation Advantages

04

Cooperation Advantages

We have many well-known partners, and upstream raw materials include brands such as Victrex in the UK and Solvay in the United States, which ensure product quality while helping customers reduce costs.

OUR STRENGTHS

  • We have 18 years of experience in production and support, with over 600 sets of injection molds.

  • Advanced detection equipment, fast response, efficient operation system.

PRODUCT DISPLAY


COOPERATION PROCESS

  • 01

    Customer drawing

  • 02

    Technical evaluation

  • 03

    Quotation

  • 04

    Mold design

  • 05

    Mold making

  • 06

    Sample approval

  • 7.jpg

    07

    Mass production

  • 8.jpg

    08

    Delivery

  • 9.jpg

    09

    After-sales support
